Scope of application: Non marking process for adhesive coating and exposed adhesive coating on submachine jackets, POLO, T-shirts, etc.
Features:
1.The speed of the upper and lower rubber wheels can be independently adjusted.
2. The heating tank can independently adjust the temperature (preheating tank).
3. The adhesive groove has two types: movable and fixed, which can be selected according to the processed product.
4. Blowing mode, with two types: inter al blowing and external blowing, can be selected according to the processed product.
5. The ultrasonic upper and lower mold trimming parts can be connected as a whole and rotatea ccording to the outer contour trajectory of the lower wheel of the feeding part to achieve two processes of gluing and glue exposure.
6.Preheating and heating system.
7. Adjustable handle to adjust the height of the upper and lower wheels.
8. Speed ratio between upper and lower wheels, ultrasonic upper and lower mold motor, and conveyor motor with precise and adjustable speed ratio.

Voltage:220V 50/60Hz

Power:1500W

Compressed air:0.4-0.8MPa

Highest temperature:350℃

Previous wheel width:22mm

Next wheel width:22mm
Ultrasonic operating frequency:35kHz

Working head size:φ30 mm

Welding speed:30ft/min

The upper/lower pressure wheels can operate at different speeds, and the cutter wheel and working head can also operate at different speeds.
